PI6CBF18501具有片上端接的超低功耗5输出PCIe扇出缓冲器,PI6CBF18501ZLAIEX-13R,低功耗晶振

2022-07-12 10:16:29 康华尔电子

PI6CBF18501是一款5输出、极低功耗PCIe Gen1/Gen2/Gen3/Gen4时钟晶振缓冲器。PI6CBF18501具有片上端接的超低功耗5输出PCIe扇出缓冲器,该器件采用参考输入来扇出具有片上终端的100MHz低功耗差分晶振HCSL输出。片上端接节省了24个外部电阻,使布局更容易。每个输出的单独OE引脚提供了更轻松的电源管理。该设备使用Diodes的专有设计来实现满足PCIe Gen1/Gen2/Gen3/Gen4 要求的非常低的抖动。它提供了各种高级选项,例如通过SMBus提供不同的压摆率和幅度,因此用户可以轻松配置器件,以实现其各个板的优化性能。PI6CBF18501具有片上端接的超低功耗5输出PCIe扇出缓冲器,PI6CBF18501ZLAIEX-13R,低功耗晶振
